| Brand/Series |
GI Series |
|
| Capacitance, Junction |
150 pF |
|
| Configuration |
Single |
|
| Current, Forward, Continuous |
6 A |
|
| Current, On-State, Non-Repetitive Peak |
400 A |
|
| Current, Peak |
5 μA |
|
| Current, Reverse |
5 μA |
|
| Current, Surge |
400 A |
|
| Diameter |
9.1 mm |
|
| Dimensions |
9.1 Dia. x 9.1 L mm |
|
| Diode Type |
Rectifier |
|
| Length |
0.358" (9.1mm) |
|
| Mounting Type |
Through Hole |
|
| Number of Pins |
2 |
|
| Package Type |
P600 |
|
| Primary Type |
Rectifier |
|
| Speed, Switching |
Standard |
|
| Temperature, Junction, Maximum |
150 °C |
|
| Temperature, Operating |
-50 to 150 °C |
|
| Temperature, Operating, Maximum |
+150 °C |
|
| Temperature, Operating, Minimum |
-50 °C |
|
| Temperature, Operating, Range |
-50 to +150 °C |
|
| Thermal Resistance, Junction to Ambient |
20 °C/W |
|
| Time, Recovery |
2.5 μs |
|
| Time, Reverse Recovery |
2500 ns |
|
| Type |
High Current |
|
| Voltage, Forward |
1.25 V |
|
| Voltage, Repetitive Peak |
100 V |
|
